How Much Material for a Double Bed? Full List for a 6×6.5 Box Bed, Hydraulic Bed and 6×4 Diwan
Short answer (estimates): a king box bed (6 × 6.5 ft) with a headboard takes about four 18mm, three 12mm and one 6mm plywood sheet. A queen hydraulic bed (5 × 6.5 ft) takes about three 18mm, three 12mm and one 6mm. A 6×4 diwan with storage takes about two 18mm and one 12mm. Add about 2 sheets of 1mm laminate, 3 of liner, 20–25 m of edge band and the hardware below.
"Bed banane mein kitna kharcha aata hai?" is two bills: material (this list) and labour (agreed with your carpenter; see how carpenters charge). For today's rate on the material, send this list to +91-9212017608.
Mattress sizes first
Make the bed to the mattress, not the other way round:
| Bed | Mattress (approx.) |
|---|---|
| King | 72 × 78 inch (6 × 6.5 ft) |
| Queen | 60 × 78 inch (5 × 6.5 ft) |
| Single / diwan | 36 × 72 inch (3 × 6 ft) up to 48 × 72 inch (4 × 6 ft) |
1. King box bed (6 × 6.5 ft), with headboard
| Material | Quantity (estimate) |
|---|---|
| 18mm plywood (top platform, box sides) | 4 sheets |
| 12mm plywood (box bottom, partitions, plain headboard) | 3 sheets |
| 6mm plywood (back or cover panels) | 1 sheet |
| 1mm laminate (outside of the box and the headboard) | 2 sheets |
| Liner laminate (inside the box, underside of the lid) | 3 sheets |
| Edge band | 20–25 m |
| Lid handles or finger pulls | 2–4 |
| Hinges for the lids (if hinged) | 2–3 per lid section |
| Battens or 18mm strips for the plinth | to the carpenter's list |
The top is made in two lids (head side and foot side), so each piece is easy to lift. Keep the box off the floor on a plinth or short legs, especially on a ground floor.
2. Queen hydraulic bed (5 × 6.5 ft), with headboard
| Material | Quantity (estimate) |
|---|---|
| 18mm plywood or block board (the lifting top, box sides) | 3 sheets |
| 12mm plywood (box bottom, partitions, headboard) | 3 sheets |
| 6mm plywood | 1 sheet |
| 1mm laminate | 2 sheets |
| Liner | 3 sheets |
| Edge band | 20–25 m |
| Hydraulic (gas-lift) fittings | 1 pair, rated for the top and mattress weight |
The lifting top must be 18mm plywood or block board. The fittings pull on their screws every time the bed opens; in MDF or particle board the screws work loose. Hydraulic fittings are sold by load rating; call +91-9212017608 to check availability before you plan around a particular fitting.
3. Diwan (6 × 4 ft), with storage
| Material | Quantity (estimate) |
|---|---|
| 18mm plywood (top, box sides) | 2 sheets |
| 12mm plywood (bottom, one partition) | 1 sheet |
| 1mm laminate | 1–2 sheets |
| Liner | 1–2 sheets |
| Edge band | about 12–15 m |
A diwan often doubles as seating in the living room, so the top takes more weight at the edges. Keep it 18mm. More on diwans and takhats: plywood for a sofa, takhat or diwan.
Add-ons
| Add-on | Extra material (estimate) |
|---|---|
| 2 side tables with one drawer each | 1 × 18mm, part of a 12mm and a 6mm, 2 pairs of channels |
| Headboard with storage shelves | +1 × 18mm |
| Upholstered headboard | 12mm plywood base + foam and fabric (from an upholsterer) |
| Drawers under the bed instead of a box | 12mm sides, 6mm bottoms, 1 pair of channels per drawer |
Grade
- Upper floor, dry room: good MR plywood.
- Ground floor, damp wall, or near an AC drain: BWR. The box bottom is the first part to go when damp rises.
- BWP isn't needed for a bed.
Full guide to thickness and grade: what thickness of plywood for a bed.
FAQ
How many plywood sheets for a king size box bed? About 4 of 18mm, 3 of 12mm and 1 of 6mm, with a plain headboard. It's an estimate; check the carpenter's cut list.
Can the bed top be 12mm to save money? Only with strong battens underneath every 1.5–2 ft. Without them, a 12mm top sinks in the middle.
Plywood or block board for a hydraulic bed top? Both work in 18mm. Block board sags less over a long span; plywood holds the fitting screws well.
How much laminate for a double bed? About 2 sheets of 1mm for the outside and 3 of liner for the inside, depending on the headboard design.
